Motor Type Motor

Servo Motor

Working System

S3 (Short-time duty cycle)

Motor Power

1500W

Power Supply

1N~220V±10%

Frequency

50/60Hz

Current

13A

Output Speed (1)

4-16 rpm

Output Torque

500 N.m

Door Weight (2)

1600 kg

Motor IP Level

54 (dust and water-resistant)

Working Environment

-20°C to +50°C

Hollow Shaft

35mm/40mm

Hand Chain Length

8m

Cables Length

8m

Recommended Cycles per Hour

20

Weight

54kgs
